Tyre Tread Depth Measuring System
SKU
RAVWS102
ea (Each)
Hassle Free Returns
Ravaglioli quick check tyre tread depth measuring system for above ground, without monitor supplied with wall mounted switchboard.
Tread depth is measured as the vehicle passes over the Profiler at a max. speed of 8 km/h (5 mph).
Measuring system: Stereo cameras plus laser blade.
Measurement results are available within seconds.
Designed with no moving parts to withstanding workshop environment.
For axle loads up to 4 tons.
Profiler is an important equipment for the reception bay, to improve the process and save time – Tyre tread on all wheels is measured very fast: before the driver exits the vehicle, all results are available.
Internet connection not required.
Suitable for both indoor and outdoor installtion (provided there is a roof covering)
RAVWS102 – Workshop reception kit: Profiler kit to be connected to the workshop’s system
Includes one electrical box complete with PC to be connected to the existing workshop PC
TEST RESULT – Two visuals available, indication of maximum / minimum values or average centre and side tread depth.
ZOOM FUNCTION – Allows selection of each tyre for a detailed analysis
AUTOMATIC TEST MEMORY – Facility available where the Profiler can be set with automatic plate registration function: the system stores the diagnostic data automatically without the presence of a technician.
VEHICLE DIAGNOSIS – Uneven tyre tread wear indicates the need for wheel alignment adjustment and suspension analysis.
WEB PAGE VISUALIZATION – Test results can be checked in the program and also on a web page from any mobile device or PC in the workshop. Test results can be accessed both on a web page and in the program
If you require additional information please do not hesitate to use the enquire button on this site and a member of our sales team will contact you to discuss your requirements in more detail 01302 718226
